Removal and installation of footwell light (on lower left sound insulation board assembly of instrument panel)

Remove

  1. Power off the low-voltage electrical system. Refer to Power-off and power-on of low-voltage electrical system

  2. Remove the lower left sound insulation board assembly of instrument panel. Refer to Removal and installation of lower left sound insulation board assembly of instrument panel

  3. Rotate the footwell light counterclockwise by 45° to take it out.

Install

  1. Install it in the reverse order of removal.
